sysWORXX CTR-500

The smart gateway solution

Highest connectivity in a small space

[DeepL] sysWORXX CTR-500

Our sysWORXX CTR-500 combines all the advantages of a PLC, an edge controller and a gateway. Fast, compact and powerful, it can be integrated into applications in the shortest possible time, just like its big brother, the CTR-700.

We take the binding of IT and OT to a new level. Scalable in functionality and interfaces, the sysWORXX CTR-500 is a multi-talent in a small space. With our sysWORXX CTR-500, you can test and expand your IoT concept without large upfront investments, thanks to fast and flexible integration.

Get started immediately!

Your advantages

  • individual scalability: assembly and design options, white and brand labels
  • high field and wireless connectivity in a small space
  • freely programmable open source component for automation or digitization
  • powerful and immediately usable with all standard partner solutions
  • Your challenge - our solution

    Accelerate your solution rollout with out-of-the-box connectivity.
    Agents tuned to our sysWORXX CTR-500 offer you:

    • Remote access in shell and web access
    • Real-time data visualization on edge and cloud
    • Monitoring and alarming, port forwarding
    • Configuration management
    • Receive device metrics and CVE security analysis
    • Docker (container virtualization)

    And much more....

    Application scenarios

    • Freely programmable open source component for automation or digitization.
    • Field gateway, edge controller, compact PLC
    • Mesh controller and sink (wirepas massive)
    • low cost IO controller
    • Climate data acquisition, asset tracking, energy monitoring and device management.

    Our partner solutions:

    • Teamviewer IoT Agent
    • qBee Device Management
    • wirepas massive pure mesh connectivity:
      • IO Mesh for climate data monitoring
      • for tracking / localization solutions
  • Software + Programming

    [DeepL] sysWORXX CTR-500 SW

    Programmability? No question!

    Our CTR-500 also speaks the languages of your employees. As a controller, it is freely programmable and configurable for all requirements and supports modern high-level languages as well as the execution of IED 61131-3 PLC programs and Linux-based applications. As a basic component for your development, there are hardly any limits to your ideas.

    • C/C++, C#, Java, Python
    • Node-RED Runtime with sysWORXX specific nodes
    • OpenPCS integration IEC 61131-3
  • Customization

    Our modules and controllers are flexibly adaptable to your needs:

    • White- & Brandlabel
    • individual assembly and design options
    • Standard assembly options:
      • Meshnet sink node - without IOs
      • Low cost IO without additional connectivity interfaces
      • Security/Authentication IC Microchip ATECC608B-SSHDA-B

    Whether you need to serve a different form factor, temperature range or special environmental conditions - we have the basic technology

    for your solution!

  • Features / Details

    • WLAN and Meshnet interface on board (Pigtail RP-SMA)
    • independent Ethernet interfaces for secure separation of enterprise IT and store floor OT
    • use of various protocols:
      • CAN, CANopen (incl. CANopen manager service for integration of other CANopen modules)
      • Modbus RTU and TCP
      • OPC UA
      • MQTT
    • suitable for DIN-rail mounting

    Physical



    Size (height, width, depth)

    61x108x91mm

    Temperature

    0°...55°C

    Humidity

    10 - 95% non-condensing (VDE 0110)

    CPU



    Processor

    NXP i.MX 7

    Processor core

    Dual Cortex-A7

    MPU speed (MHz)

    1000

    MIPS

    3800

    RTC

    Yes

    Temp. sensor

    Yes

    Memory



    RAM

    1024 MB

    Storage

    8GB eMMC

    Connectivity



    WLAN

    1 (pigtail RP-SMA)

    Meshnet

    1 (wirepas massive pure mesh connectivity, Pigtail RP-SMA)

    Ethernet

    2x 1Gbps (Secure separation of IT & OT)

    CAN

    1 (CANopen, CAN Layer 2), (2nd optional)

    SIO

    2 (RS485 Modbus, RS232 freely available)

    USB Host

    1

    SD Card

    1

    Linux console

    1 (Version as USB or RS232)



    Prepared for use with all major cloud providers through standard protocols such as MQTT, OPC-UA and REST

    Cloud

    Prepared for use with all major cloud providers

    Software



    Basic installation

    Linux OS (Debian 10 Buster), I/O drivers, Node-RED incl. sysWORXX nodes for I/O access and data exchange with IEC 61131-3 Runtime OpenPCS, OpenJDK & Mono, Docker (container virtualization)

    Additional licenses

    IEC 61131-3 Runtime OpenPCS, OPC UA server for OpenPCS

    Optional

    Third party software: Download via Debian OS repositories



    TeamViewer Agent for connection to TeamViewer Cloud



    qBee Agent for Device Management via Cloud

    I/O interfaces



    Digital inputs 24 VDC

    4 (data galvanically decoupled)

    Digital outputs 24VDC, 0.5 A

    4

    Displays



    Switch

    Run/Stop, Config, Reset, Boot

    Status LEDs

    Power CPU, Power periphery, Run, Error & more

    Maintenance access

    SSH/SFTP

    Current consumption

    24V, 1.5A supply - typical consumption 0.1A (without digital outputs)

  • Documents & downloads

  • Ordering information

    Art. No.

    Description

    19031001

    sysWORXX CTR-500 incl. microUSB cable, antennas

    240011

    Runtime license OpenPCS RT

    240012

    Runtime license OPC-UA basic server

    149018

    Power supply & connection cable for laboratory or test use
